WOBBF182
Busbar Insulated Fork 80A 2 Pole 18 Module Purple
SKU
WOBBF182
Box Qty
16
Categories
Busbar
Features
- Designed for two module RCBO's where feed in for Active + Neutral Bar
- Rated current In, busbar comb, end feed 80A
- Rated Voltage 230V/400V
- Type connection Fork type
- Number of phases 2 or 1+N
- Number of modules 18
- Insulated sleeve
- Can be suitable for devices with N-conductor
- Module width 18mm
- Cross section 16mm²
Product specs
Dimensions
31.6mm x 9.9mm x 31.4mm
Voltage
230
Amperage
80
Module
18
Poles
2
Material
Steel
Surface finish
Gloss
