PUSWV4G66
Switch Vertical 4 Gang 10AX 250V ac IP66
SKU
PUSWV4G66
Box Qty
5
Categories
Switches IP66
Features
- Trader IP66 rated flush switches have been designed to achieve IP66 on a smooth, flat, non_x0002_porous surface, from the front of the switch only.
- The switches are compatible with mounting hardware for standard 84mm mounting centre wallplates.
- IP Rating : IP66 (from front only).
- Voltage Rating: 250V a.c
- Current Rating: 10AX.
- Motor Rating: M100
- No provision has been made to prevent water and dust entering from behind the switch.
- Care should be taken when mounting, to ensure that water and dust cannot bypass the gasket and come in contact with live parts.
- Ensure that the mounting surface is completely flat, smooth and non-porous.
- Make sure the rear gasket seal is located in its correct position. – Use the silicone washer.
- Clip on front cover/surround.
- Standard colour is white. PUSWV4G66 & PUSW4G66 also available in Black & Matt Black - please check availability-
Product specs
Dimensions
120mm x 75mm x 40mm
Voltage
250
Amperage
16
Switch rating
10
Poles
1
Material
Polycarbonate
Surface finish
Gloss
Puma PUSWV4 G66
Download to see product technical details.
