HYPP1GSBK
Surface Socket Small 10A 250V ac Three Pins Diameter 59mm Black
SKU
HYPP1GSBK
Box Qty
10
Categories
Surface Sockets
Features
- Quality round tunnel terminals with a 6mm bore to provide plenty of wire space
- Depth 51mm (including backing plate)
- 10A 250V~ Three Pins
- Combination head screws
- Clean precision break out features for TPS cabling
- The backing plate has raised edges with clean breakouts and apertures for TPS cabling
- Nail plate entry and exit points
- Multiple fixing points including external tabs, for cable ties, clouts and screws
- Cover push clips onto backing plate
- Quality round tunnel terminals with a 6mm terminal bore for plenty of wiring space
- Pin Locating Ribs allow the installer to determine the orientation of the Surface Socket without looking at it. This makes inserting the plug simple.
- Standard colour is green, also available in black.-
Product specs
Dimensions
88mm x 60mm x 51mm
Voltage
250
Amperage
10
Poles
1
Material
Polycarbonate
Surface finish
Gloss
Hyena HYPP1 GSBK
Download to see product technical details.
