HPISWL463
Isolator Switch Weatherproof IP66 63A 440V 4 Pole Large Grey
SKU
HPISWL463
Box Qty
1
Categories
Isolators
Features
- Hippo Isolators are tested to AS/NZS3133 and AS/NZS IEC60947-3.
- The Hippo larger enclosures feature twin 25mm threaded entries both top and bottom.
- The internal isolator switch modules are base mounted to provide a stable platform for wiring.
- More detail for switches can be seen in the table on following page.
- Packaging lid features cutting template for easy marking out.
- UV stabilised
- Colour: Grey. Also available in Black, please check availability. The switches feature:
- Combination head terminal screws
- Combination head earth and neutral terminal screws
- Alignment sleeves on switch housing guides screwdriver into terminal screws, reduces screwdriver tips jumping out.
- Terminal bores have plenty of space for wiring (see table for sizes)
- Pad lock-
Product specs
Dimensions
170mm x 80mm x 90mm
Module
Material
Polycarbonate
Surface finish
Gloss
Hippo HPISWL463
Download to see product technical details.
