HPAIBK

Appliance Inlet Weatherproof Single Inlet IP34 15A 250V Black Cover Caravan Ready

SKU

HPAIBK

Box Qty

1

Categories

Caravan

Features

  • These weatherproof appliance inlet are ideal for caravans or powering relocatable buildings.
  • It is rated at 15A 250V ~ to provide adequate power input capability to cover accessories and equipment used in most portable dwellings.
  • The HPAI has insulated safety pins to prevent accidental electrical contact and a recess placed in the inlet to allow the acceptance of a 15A shrouded cord extension socket.
  • The flap on the HPAI is designed to be able to close over standard extension sockets and provide an adequate weather protection rating to IP34.
  • The flap contains a flexible seal that hugs over the cable to help maintain the IP rating while it is in use.
  • The product comes with a foam gasket for sealing against the mounting surface and a separate mounting flange for use in cases where wall panelling is thin and wiringspace is limited.
  • UV stabilsed polycarbonate to resis yellowing from sunlight.
  • Standard colour is White. Also available in Black - please check availability.
  • Terminals are suited for 1.5mm2 or 2.5mm2 cables.-

Product specs

HPAI Specs

Dimensions

120mm x 80mm x 80mm

Module

Material

Polycarbonate

Surface finish

Gloss

HPAIBK Resources

Hippo HPAIBK

Download to see product technical details.
DOWNLOAD
