BUJB2
Junction Box 2 Gang IP66 2x25mm and 1x32mm Entries 40A Connectors for 3x6mm2 or 4x2.5m2 Cables Grey
SKU
BUJB2
Box Qty
1
Categories
Junction Box
Features
- Manufactured in industrial grade resins providing:
- Polycarbonate Lids for High Impact Strength.
- UV Resistance.
- Good level of Chemical Resistance.
- Back Boxes & Junction Boxes supplied with Reducers and Screw Caps.
- Compatible with Buffalo previous & current ranges.
- Grey colour.
- Includes 5 connectors (3 Phase, Neutral & Earth).
- Includes cover sealing gasket + fixing screws.
- Includes cover screw caps (BUCAP9).
- Connectors accept 3 x 6mm² or 4 x 2.5mm² cables.
- Installer Tip: Fix cover screws to maximum torque levels of 0.53Nm.-
Product specs
Dimensions
206mm x 101mm x 94mm
Module
Material
Polycarbonate
Surface finish
Gloss
Data Sheets Buffalo
Download to see product technical details.
Why Choose Buffalo
Buffalo
Click to discover why Buffalo is the ideal choice for your needs!
Buffalo BUJB2
Download to see product technical details.
Buffalo Range Flyer
Buffalo
Download to explore the full Buffalo range.
Buffalo Data Sheet
Buffalo
Download to see technical details for the complete Buffalo range.
